PEIF Filterability Index Unit

13.1.- HYDROLOGY AND HYDROGEOLOGY
FILTERABILITY INDEX UNIT - PEIF

INNOVATIVE SYSTEMS

This unit utilises a bed of granular material, normally sand, which can be chosen by the student to suit his own purposes. The measurements taken with this unit enable a filterability index to be calculated which has significance in deep bed filter performance.

See general description

Expansions

ICAI

Interactive Computer Aided Instruction Software

Laboratories

13TV
 Environmental Laboratory for Vocational and Technical Education
13HE
 Environmental Laboratory for Higher Education

RELATED NEWS

CO₂ adsorption: a current necessity
CO₂ adsorption: a current necessity
In a world where climate change represents one of the greatest threats to our future, carbon dioxide (CO2) adsorption has become an urgent priority. The increasing concentration of CO2 in the atmosphere, primarily driven by human activities such as fossil fuel combustion and deforestation, has...
Read more
EDIBON and its commitment to European Skills
EDIBON and its commitment to European Skills
At EDIBON, we are committed to strengthening skills as a strategic pillar for the competitiveness and social well-being of the European Union. Proper training not only boosts the economy but also enables individuals to fully participate in society and democracy.
Read more
Everything You Need to Know About Direct Air Capture (DAC) and Its Impact on Climate Change
Everything You Need to Know About Direct Air Capture (DAC) and Its Impact on Climate Change
Direct Air Capture (DAC) is an innovative technology that removes CO₂ directly from the air using chemical reactions with liquid solvents or solid absorbents. Despite challenges such as high costs and energy consumption, DAC offers a potential solution to reduce atmospheric CO₂ concentrations and...
Read more
Understanding and improving drinking water treatment systems
Understanding and improving drinking water treatment systems
Ensuring access to safe drinking water involves complex processes and advanced technologies. Key components of a treatment plant include intake structures, coagulation, flocculation, sedimentation, filtration, disinfection, storage, and distribution. Modern systems use reverse osmosis, UV...
Read more

General Description

This unit utilises a bed of granular material, normally sand, which can be chosen by the student to suit his own purposes.The measurements taken with this unit enable a filterability index to be calculated which has significance in deep bed filter performance.

The "PEIF", unit is a bench-top unit composed of a feeding tank, where the initial solution of water with solids in suspension is placed. During the normal operation, the tank is communicated with the sand filter upper part, through of a pipe.

The filter lower part is communicated with the flowmeter. A regulation valve located at the flowmeter allows to change the flow which passes through the filter.

The fluid pressure is obtained by means of the gravity, because the feeding tank is placed in high. The pressure is measured by a manometer.

The filter cartridge is easily removable, so it allows to study the difference between different media, both in compositions and in mesh.

This unit, in addition to students teaching and training, also can be used in routine control at water purification works, or at water treatment works which employ tertiary filtration.

Exercises and guided practices

GUIDED PRACTICAL EXERCISES INCLUDED IN THE MANUAL

  1. Study of the filtration operation principles.
  2. Study of Darcy equation.
  3. Deep bed filtration of suspensions with different beds.
  4. Calculation of Filterability Index.
  5. Sand filter cleaning.
