M11/KIT Kit de Fondamentaux de l'Électronique Numérique

2.2.- KIT POUR L'ASSEMBLAGE DE CIRCUITS

SYSTEMES INNOVANTS

With Digital Electronic Fundamentals Kit, "M11/KIT", designed by EDIBON, numbering systems, logic circuits, TTL gates, CMOS, Boolean algebra, etc. can be studied.

Voir description générale

Catalogue

Spécifications du Concours

Expansions

ICAI

Logiciel Interactif pour l'Enseignement assisté par Ordinateur

Laboratories

2TV

Laboratoire d'électronique pour l'enseignement Technique et Professionnel

NOUVELLES LIÉES

Description Générale

With Digital Electronic Fundamentals Kit, "M11/KIT", designed by EDIBON, numbering systems, logic circuits, TTL gates, CMOS, Boolean algebra, etc. can be studied.

Des exercices et pratiques guidées

EXERCICES GUIDÉS INCLUS DANS LE MANUEL

Numbers systems:

Voltage measurement in a circuit of sources.
Faults study in the source circuit.
Theoretical/practical exercises.

Logical circuits:

Logical Diode.
Fault study in sources.
Logic with transistor and diodes.
Faults study in transistor/diode circuit.
Theoretical/practical exercises.

TTL gates:

Basic function gates.
Faults study in TTL circuit.
Faults study in Logic Gates.
Theoretical/practical exercises.

CMOS gates:

Basic function gates.
Faults study in CMOS circuit.
Theoretical/practical exercises.

Boolean Algebra and logical functions:

Study of use of circuit#3 (TTL logical gates).
Theoretical/practical exercises.

Open collector gates:

Study of the use of circuit#5 (Open collector gates).
Theoretical/practical exercises.

Others types of integrated gates:

Study of simple operations with a Schmitt Trigger inverter.
Operation study of a three-state buffer.
Study of the fault in the circuit#7 (Three-states).
Theoretical/practical exercises.

PLUS D'EXERCICES PRATIQUES À EFFECTUER AVEC CETTE ÉQUIPEMENT

JK Flip-Flop.
Control of Data Bus.
Several other exercises can be done and designed by the user.

ÉLÉMENTS REQUIS

UNITÉS SIMILAIRES DISPONIBLES

DIGITAL ELECTRONICS FUNDAMENTALS MODULE - N-M11

N-M11

Available

14.2.1.3.- ÉLECTRONIQUE NUMÉRIQUE

N-M11

Module de Base de l'Électronique Numérique

Les systèmes numériques sont des systèmes de traitement, de traitement ou de transmission d’informations, dans lesquels l’information se limite à prendre des valeurs dans un ensemble discret. Ces signaux (dont l’amplitude ne peut prendre qu’une...

EQUIPEMENT COMPLEMENTAIRE

BASIC ELECTRONICS AND ELECTRICITY ASSEMBLY KITS: - M-KITS

M-KITS

Available

2.2.- KIT POUR L'ASSEMBLAGE DE CIRCUITS

M-KITS

Kits de Montage d´Électronique et d´Électricité de Base :
