MEC オーバードライブ実験装置

7.2.2.- ギア、 ディファレンシャル、 トランスミッション
OVERDRIVE UNIT - MEC

革新的なシステム

The Overdrive Unit, "MEC", includes a set of epicyclical gears that represent an application of a simple epicyclic arrangement of the type used in a motor vehicle overdrive.

一般的な説明を表示

拡張

ICAI

インタラクティブなコンピュータ支援教育ソフトウェア
MSAC

モジュラーな取得および制御システム

研究室

7TV
 機械・自動車・材料研究室
7HE
 高等教育のための機械・自動車・材料研究室

関連ニュース

EDIBON and its commitment to European Skills
EDIBON and its commitment to European Skills
At EDIBON, we are committed to strengthening skills as a strategic pillar for the competitiveness and social well-being of the European Union. Proper training not only boosts the economy but also enables individuals to fully participate in society and democracy.
続きを読む

概要

The Overdrive Unit, "MEC", includes a set of epicyclical gears that represent an application of a simple epicyclic arrangement of the type used in a motor vehicle overdrive.

Simple epicyclic set consists of:

  • Sun gear that rotates together with the input shaft.
  • Planet gears whose carrier can rotate.
  • Ring gear that rotates together with the output shaft.

In the "MEC" unit the power reaches the epicyclic gear through the central sun gear, that is to say, the input shaft is joined to the central sun pinion and the output power is obtained at the output shaft because it is joined to the ring.

This unit allows the student to study the reduction ratios of overdrive, as well as torque conversion.

演習と指導の慣行

マニュアルに含まれるガイド付き実習

  1. To study the overdrive speed.
  2. To demonstrate the operation of an epicyclic gears system to obtain the overdrive speed.
  3. To determine the angular displacement at the input and output and to compare it with the overdrive reduction ratio calculated.
  4. To determine the minimum effort required at the input to raise a load at the output in an overdrive reduction ratio.
  5. Power transmission: checking the ratio between input torque and output torque for an overdrive reduction ratio.
