EEU/20KN ユニバーサル素材試験装置

7.3.2.1.- 機械的試験 14.1.8.- 機械的試験
UNIVERSAL MATERIAL TESTING UNIT - EEU/20KN

革新的なシステム

The Universal Material Testing Unit, "EEU/20KN", is a didactic bench-top universal material testing unit.

一般的な説明を表示

拡張

ICAI

インタラクティブなコンピュータ支援教育ソフトウェア
MSAC

モジュラーな取得および制御システム

関連ニュース

EDIBON and its commitment to European Skills
EDIBON and its commitment to European Skills
At EDIBON, we are committed to strengthening skills as a strategic pillar for the competitiveness and social well-being of the European Union. Proper training not only boosts the economy but also enables individuals to fully participate in society and democracy.
続きを読む
Installation at University of Sebha
Installation at University of Sebha
Today, we can announce the setting up of a complete installation, including the Linear Heat Conduction Module TXC/CL, TXC/CC, TTEC, MINI-EEE, EEU/20KN or EBVR, among others, at the University of Sebha, in Libya. We are confident that this new equipment will allow students to test empirically the...
続きを読む
NEW Photoelasticity course
NEW Photoelasticity course
Are you a teacher or do you work as an engineering researcher? EDIBON offers courses for teachers and #research staff. Take a look at the course of Photoelasticity and learn about #elasticity, #fracturemechanics and #materialtesting. #DiscoverEdibon #Engineering.
続きを読む
NEW Strength of Materials Course
NEW Strength of Materials Course
Are you a teacher or do you work as an engineering researcher? EDIBON offers courses for teachers and #research staff. Take a look at the course of 12 days of material resistance and learn about #energy theorems. #DiscoverEdibon #Engineering Contact us for further information!
続きを読む

概要

The Universal Material Testing Unit, "EEU/20KN", is a didactic bench-top universal material testing unit. It is distinguished by its rigid construction, accurate control and a precise hydraulic system to apply loads of up to 20 kN, which enables demonstrations of phenomena undetectable under smaller loads.

With this unit the student can perform these material tests:

  • Shear test.
  • Brinell hardness test.
  • Compression test.
  • Tensile test.
  • Deep draw (cupping) test.
  • Bending test.
  • Disc and helical spring tests.

It allows achieving testing forces up to 20 kN with very little physical effort.

The measurements can be obtained either manually through an elongation gauge and a dynamometer or through the computer data acquisition system giving accurate real-time data capture, monitoring and display, calculation and results representations on the computer.

演習と指導の慣行

マニュアルに含まれるガイド付き実習

  1. Learning how to use the instrumentation required to perform the main tests on materials.
  2. Study and familiarization with universal material testing machines.
  3. Tensile strength tests.
  4. Compressive strength tests.
  5. Brinell hardness tests.
  6. Bending tests.
  7. Shear tests.
  8. Deep draw (cupping) tests.
  9. Tests with disc springs.
  10. Tests with helical springs either in series or in parallel.
  11. Recording stress-strain diagrams.
  12. Using the computer data acquisition system.
