The Computer Controlled Tubular Flow Reactor for QRC, "QRTC", has been designed by EDIBON to conduct the kinetic study of homogeneous liquid-liquid reactions. In this unit, a continuous stream of reactants is passed through, which mix and react as they flow through the unit.
