1130 SPECIAL CHEMICAL PROCESS. Advanced Module

EDUCAÇÃO TÉCNICA SUPERIOR QUÍMICA ENGENHEIRO QUÍMICA ENGENHARIA DE PROCESSOS CENTRO DE FORMAÇÃO DE PETRÓLEO CENTRO INTERNACIONAL DE FORMAÇÃO TÉCNICA, DESENVOLVIMENTO E INVESTIGAÇÃO ESCOLAS TÉCNICAS QUÍMICA INDUSTRIAL QUÍMICA
Solicitar informação

Expansões

PLC

Controle de Processos Industriais por CLP
ECL

Educação a Distância EDIBON
FSS

Sistema de Simulação de Falhas
ICAI

Software Interativo para Educação Assistida por Computador
ELK

Kit de Desenvolvimento de Software EDIBON, Desenvolvido por NI LabVIEW ™

EXERCÍCIOS E PRÁTICAS GUIADAS

EXERCÍCIOS PRÁTICOS GUIADOS INCLUÍDOS NO MANUAL

  1. Determination of the curves M (n, Ha), N (n, Ha), η (n, Ha).
  2. Determination of the curves M (n, Q), Nm (n, Q), η (n, Q).
  3. Adimmensional analysis.
  4. Sensors calibration.Practices to be done by PLC Module (PLC-PI)+PLC Control Software.
  5. Control of the TFRC unit process through the control interface box without the computer.
  6. Visualization of all the sensors values used in the TFRC unit process.
  7. Calibration of all sensors included in the TFRC unit process.
  8. Hand on of all the actuators involved in the TFRC unit process.
  9. Realization of different experiments, in automatic way, without having in front the unit. (This experiment can be decided previously).
  10. Simulation of outside actions, in the cases do not exist hardware elements.(Example: test of complementary tanks, complementary industrialenvironment to the process to be studied, etc).
  11. PLC hardware general use and manipulation.
  12. PLC process application for TFRC unit.
  13. PLC structure.
  14. PLC inputs and outputs configuration.
  15. PLC configuration possibilities.
  16. PLC program languages.
  17. PLC different programming standard languages (literal structured, graphic, etc.).
  18. New configuration and development of new process.
  19. Hand on an established process.20- To visualize and see the results and to make comparisons with the TFRC unit process.
  20. Possibility of creating new process in relation with the TFRC unit.
  21. PLC Programming Exercises.
  22. Own PLC applications in accordance with teacher and student requirements.
