LFFC Computer Controlled Fixed and Fluidized Bed Unit

11.1.1.- 流化
COMPUTER CONTROLLED FIXED AND FLUIDIZED BED UNIT - LFFC

Unit: LFFC. Computer Controlled Fixed and Fluidized Bed Unit

COMPUTER CONTROLLED FIXED AND FLUIDIZED BED UNIT - LFFC

Complete LFFC unit

COMPUTER CONTROLLED FIXED AND FLUIDIZED BED UNIT - LFFC

Unit details

COMPUTER CONTROLLED FIXED AND FLUIDIZED BED UNIT - LFFC

LFFC/CIB. Control Interface Box: The Control Interface Box is part of the SCADA system

COMPUTER CONTROLLED FIXED AND FLUIDIZED BED UNIT - LFFC

Process diagram and unit elements allocation

COMPUTER CONTROLLED FIXED AND FLUIDIZED BED UNIT - LFFC

LFFC/SOF. LFFC Software. Main Screen

COMPUTER CONTROLLED FIXED AND FLUIDIZED BED UNIT - LFFC
COMPUTER CONTROLLED FIXED AND FLUIDIZED BED UNIT - LFFC
COMPUTER CONTROLLED FIXED AND FLUIDIZED BED UNIT - LFFC
COMPUTER CONTROLLED FIXED AND FLUIDIZED BED UNIT - LFFC
COMPUTER CONTROLLED FIXED AND FLUIDIZED BED UNIT - LFFC
COMPUTER CONTROLLED FIXED AND FLUIDIZED BED UNIT - LFFC

創新系統

The Computer Controlled Fixed and Fluidized Bed Unit, "LFFC", allows a full study about everything concerning the flow of a fluid through a particles bed, both fixed and fluidized.

查看一般說明

扩展

ICAI

交互式计算机辅助教学软件
FSS

故障模拟系统
PLC

PLC控制工业过程
PLCHMI

带有HMI的本地/远程IIoT控制和监控
ELK

EDIBON软件开发工具包，由NI LabVIEW™提供支持
ECR

EDIBON的模块化工业系统与NI CompactRIO
ESN

EDIBON Scada-Net系统
ECL

EDIBON 远程教育

化验室

11TV
 技术和职业教育化学工程实验室
11HE
 高等教育化学工程实验室
11PTC
 石油培训中心实验室

相關新聞

EDIBON and its commitment to European Skills
EDIBON and its commitment to European Skills
At EDIBON, we are committed to strengthening skills as a strategic pillar for the competitiveness and social well-being of the European Union. Proper training not only boosts the economy but also enables individuals to fully participate in society and democracy.
阅读更多
Second-generation biofuels: the sustainable future at EDIBON
Second-generation biofuels: the sustainable future at EDIBON
In a world where energy demand continues to rise and non-renewable resources are rapidly depleting, the need for sustainable, environmentally friendly solutions has never been more urgent. The circular economy and the use of organic biomass to produce biofuels are emerging as key answers to...
阅读更多
Setting up at University of the Punjab, Pakistan.
Setting up at University of the Punjab, Pakistan.
Our local representative just completed an installation at University of the Punjab, Pakistan. There we installed equipment like the HCMP; AFTC; PBSPC; HVCC; EMLS; LFFC; LIFLUBA; FME00; TMTC; TSTCC; EESTC; EESFC; EE-KIT; EEEC; EEF; EBEC; EBDC; TTEC; SFU; RETU, among others. Our cutting-edge...
阅读更多
Chemical Engineering and its Processes
Chemical Engineering and its Processes
Chemical engineering is a fascinating discipline that merges chemical science with engineering to create and optimize processes that transform raw materials into valuable products. In this journey into the heart of chemical engineering, we will explore various key aspects, from chemical reactors...
阅读更多

一般說明

The Computer Controlled Fixed and Fluidised Bed Unit, "LFFC", allows a full study about everything concerning the flow of a fluid through a particles bed, both fixed and fluidised.

The unit is composed of two transparent removable columns for the simultaneous study of the air and water flow through the bed.

In the Computer Controlled Fixed and Fluidised Bed Unit, "LFFC", the pressure drop caused by the bed is measured by a differential pressure sensor connected to each column.

Water is pumped from a tank, located at the back side of the unit, to the bottom of the first column, passing through a flow control valve and a flow sensor.

Air is supplied to the second column through a compressor located at the back of the unit. The air flow is measured by a differential pressure sensor and an orifice plate.

There are glass beads of two different sizes for the bed.

This Computer Controlled Unit is supplied with the EDIBON Computer Control System (SCADA), and includes: The unit itself + a Control Interface Box + a Data Acquisition Board + Computer Control, Data Acquisition and Data Management Software Packages, for controlling the process and all parameters involved in the process.

練習和指導練習

手册中包含的指导实践练习

  1. Study of the basis of fixed bed fluidisation.
  2. Comparison of the fluidisation process in water and air currents.
  3. Study of the pressure drop through fixed and fluidised beds in function of:
  • The flow speed.
  • The size of the bed particles.
  • Type of fluid: air or water.
  1. Verification of Carman-Kozeny equation.
  2. Study and determination of the minimum fluidisation speed.
  3. Study and determination of the fluidisation speed and comparison with theoretical calculated values (Ergun equation).
  4. Study of differences between particulate and aggregative fluidisation.
  5. Observation of the "bubbling" fluidisation phenomenon.
  6. Sensors calibration.

与该单位进行更多实际操作

  1. Many students view results simultaneously. To view all results in real time in the classroom by means of a projector or an electronic whiteboard.
  2. Open Control, Multicontrol and Real Time Control. This unit allows intrinsically and/or extrinsically to change the span, gains, proportional, integral, derivative parameters, etc, in real time.
  3. The Computer Control System with SCADA allow a real industrial simulation.
  4. This unit is totally safe as uses mechanical, electrical and electronic, and software safety devices.
  5. This unit can be used for doing applied research.
  6. This unit can be used for giving training courses to Industries even to other Technical Education Institutions.
  7. Control of the LFFC unit process through the control interface box without the computer.
  8. Visualization of all the sensors values used in the LFFC unit process.
  9. By using PLC-PI additional 19 more exercises can be done.
  10. Several other exercises can be done and designed by the user.
