일반적인 설명

The Computer Controlled Plug Flow Reactor for QRC, "QRPC", designed by EDIBON, allows studying and investigating the kinetics of reactions and flow behavior in chemical systems. A plug flow reactor is a type of tubular reactor that assumes the assumption of no axial mixing of components along its length.

This type of reactor requires the application of a series of specific formulas over a volume differential instead of over the total volume, as is the case with perfectly mixed reactors.

This reactor enables the determination of key kinetic equations, such as the basic hydrolysis of ethyl acetate, which is fundamental for the design and optimization of industrial processes. It facilitates comparative analysis between theoretical and experimental conversion values, enhancing understanding of chemical processes.

Additionally, it examines the effect of flow rate and feed concentration on reaction efficiency and selectivity. Its ability to investigate the influence of temperature on laminar flow characterization is essential for optimizing chemical processes under variable conditions. Furthermore, it studies the reactor’s response to disturbances, such as pulses and step changes, providing vital information for the design and control of industrial chemical processes.

In summary, the piston flow reactor enables a wide range of practices and experiments, making it an invaluable tool for researchers, educators, and industry professionals seeking to understand and optimize complex chemical processes.

To work with this reactor, the Base and Service Unit, "QUSC", is required, which supplies the necessary reagents and thermostatic water for proper operation.

These Computer Controlled Units are supplied with EDIBON Computer Control System (SCADA), and includes: The unit itself + a Control Interface Box + a Data Acquisition Board + Computer Control, Data Acquisition and Data Management Software Packages, for controlling the process and all parameters involved in the process.

연습 및 가이드

매뉴얼에 포함 된 가이드 실기 연습

  1. Determination of the residence time distribution of the reactor.
  2. Effect of flow rate and feed concentration on the determination of flow pattern.
  3. Study of the reactor response to different perturbations: step and pulse change.
  4. Effect of flow rate and feed concentration on the steady state conversion.
  5. Demonstration of the flow pattern in the reactor and comparison with the theoretical model.
  6. Determination of the steady state conversion of a second order reaction.
  7. Understanding the principles of tracer techniques in flow pattern characterisation.
  8. Conductivity measurement system: conductimeter.
  9. Sensors calibration.

장비로 수행 할 수있는 더 많은 실용적 연습

  1. Détermination de la distribution des temps de séjour dans le réacteur.
  2. Effet du débit et de la concentration de l'alimentation sur la détermination du schéma d'écoulement.
  3. Étude de la réponse du réacteur à différentes perturbations : changement par étapes et par impulsions.
  4. Effet du débit et de la concentration d'alimentation sur la conversion en régime permanent.
  5. Démonstration de la configuration de l'écoulement dans le réacteur et comparaison avec le modèle théorique.
  6. Détermination de la conversion en régime permanent d'une réaction du second ordre.
  7. Compréhension des principes des techniques de traçage dans la caractérisation de l'écoulement.
  8. Étude du système de mesure de conductivité : conductimètre.
  9. Calibrage des capteurs.
